22
Basic operation (to be continued)
2.Window
This TV supports no higher than 60Hz under PC mode, so please set the refresh
rate of PC to 60Hz. If the frequency is higher than 60Hz, the screen may flicker.
When the TV is in PC mode, press MENU button on the remote control. Press
t / u
Arrow button to select
“WINDOW”.
1) Adjusting picture H-Position
Press
q / p Arrow button to select
“H-POSITION” and press t / u Arrow button to
set horizontal position of picture.
2) Adjusting picture V-Position
Press
q / p Arrow button to select
“V-POSITION” and press t / u Arrow button to
set vertical position of picture.
3) Adjusting Clock
When PC is connected to TV set because of the difference of PC parameter,you
should adjust the
“CLOCK” item in “WINDOW” menu until you get a good picture.
4) Adjusting Phase
When PC is connected to TV set because of the difference of PC parameter,you
should adjust the
“PHASE” item in “WINDOW” menu until you get a good picture.
5) Auto Adjust
If there are unexpected problems happened when you adjust the items, you can
select the
“AUTO ADJUST” and press u Arrow button, the TV set will resume the
original settings.
Note: Only
“H-Position” and “V-Position” are available for YPBPR mode.
PICTURE AUDIO WINDOW FUNCTION SETTING
MENU EXIT SELECT ADJUST
PHASE
AUTO ADJUST
CLOCK
V-POSITION
H-POSITION 100
100
100
0
PICTURE AUDIO WINDOW FUNCTION SETTING
MENU EXIT SELECT ADJUST
V-POSITION
H-POSITION 100
100
