12
WIRING DIAGRAM
GND L N
YL/GN
BK WH
RD
WH
BR
BK
BU
YL
Push Button Switch
La
L3
M
1
2
YL/GN
BK
BR WH
YL RD WH BK
Z
YL/GN
BU
YL RD WH BK GY
SE13FD
M
BU
YL
BU
YL/GN
GY BK RD WH YL BR
Switch Operation
Position
Off
Lamps
Low Speed
Med Speed
High Speed
Function
No Connection
Brown-Blue-Yellow
(L - LA)
Brown-Blue-White
(L - 1)
Brown-Blue-Red
(L - 2)
Brown-Blue-Black
(L - 3)
Blue - Black
Blue - Gray
Blue - Red
Blue - White
Room Temp.
73.4˚F 23˚C
45.1
37.7
30.3
28.8
Motor
Characteristics
Power Supply
Frequency
Power Absortion 240 Watts
60 Hz
120 VAC
