4
BENEfITS AND fEATURES
Your washer has several benefits and features which are summarized here. Some items may not apply to your model.
features
Innovative features
Your new washer includes these features that help to reduce noise,
increase the ease of use, and improve wash performance.
Electronic Controls
Electronic controls with preset cycles are easy to use whether you
are a beginner or an “expert.”
Quiet Operation
This washer is insulated with sound-dampening materials to reduce
washer operation sounds and noises.
Suspension System
To reduce washer “vibration,” “walk,” and “out of balance”
conditions, your new washer combines:
4 Spring damper struts to isolate vibration
■ ■
Balance ring at the top and bottom of the wash basket to
■ ■
minimize vibration
Operating software designed to sense and correct off-balance loads
■ ■
Clean Washer with AffRESH ™ Cycle
This washer features an easy-to-use Clean Washer with AFFRESH ™
cycle that thoroughly cleans the inside of your washing machine
using higher water volumes in combination with AFFRESH ® washer
cleaner or liquid chlorine bleach. The use of AFFRESH ® washer
cleaner or liquid chlorine bleach with this cycle, will remove and
help avoid odor-causing residue.
Stainless Steel Basket
The stainless steel basket is corrosion resistant and enables higher
spin speeds for more water extraction, reducing drying time.
Self-clean Wash and Rinse filter System
This washer filters 100% of the wash and rinse water. The water
is filtered then recirculated. The force filter traps sand and dirt,
flushing them down the drain, so they are not redeposited onto the
clean clothes.
Delay Start
Delay Start allows you to load your washer and pause the start of
the cycle for up to 10 hours.
End Signal - Off - Low - Hi
The End Signal produces an audible sound when the wash cycle is
finished. This signal is helpful when you are removing items from
the washer as soon as it stops.
Water Save Spray Rinse
This washer is designed to have the option of saving water by
using a spray rinse instead of a deep water rinse. This option is
the default setting on some cycles. The option is selectable on
other cycles. When using fabric softener, always select the Fabric
Softener button, or select Extra Rinse; both of these options will
dispense fabric softener in a deep rinse.
Sanitary with Oxi Cycle
This washer is NSF certified to eliminate 99.9% of bacteria when
used in conjunction with the Oxi Treat Stains option. To achieve
NSF sanitization, set the washer on the Sanitary cycle. Be sure to
add an oxygen based stain fighter.
Benefits
High-Efficiency Wash System
Your new top loading, high-efficiency washer saves you time by
allowing you to do fewer, larger loads. It also conserves resources
and lowers your water and energy bills by using the following
innovations.
INTELLIfILL™ Water Level Control
This washer senses the load size and composition through a series
of fills and wash motion. It then adjusts the water level for the best
cleaning and rinsing performance. It eliminates the guesswork. The
water level is just right for every wash load size.
NOTE: You may notice during a cycle that the wash load is not
completely submerged in water. This is normal for your washer.
Auto Temperature Control
The Auto Temperature Control system on this washer electronically
senses and maintains a uniform water temperature by regulating
incoming water temperatures. Using Auto Temperature Control will
help dissolve detergent.
Washer Impeller System
Your new washer works differently than most washers that you may
be accustomed to. The most striking difference is that the washer
has a washer impeller system. It uses this new innovative washer
impeller at the bottom of the wash basket to move your load
through a mixture of water and detergent. The load is moved from
the outside toward the middle with items coming up in the center
and down on the outside edges.
Dispensers
The dispensers make your washer truly automatic. It is unnecessary
for you to return to the washer during the cycle to add detergent,
bleach, fabric softener, laundry boosters, or oxi. Laundry products
are added to the load at the proper time in the wash cycle.
Spin Speeds
This washer is preset to automatically select the spin speed based
on the cycle selected. Depending on your wash load, you can
change the preset speeds. The spin speed on this washer is nearly
twice as fast as that of a conventional washer. You may notice
different sounds during a spin cycle because of this higher speed.
Clean Boost with Heater
The Clean Boost with Heater option helps to ensure better soil and
stain removal. Clean Boost with Heater uses the heater within the
washer to maintain the selected temperature setting throughout
the wash period. This option will add some additional time to the
cycle based on which temperature is selected. Clean Boost with
Heater reduces the need for pretreatment and is safe for all fabrics.
High Efficiency (HE) Detergent
This washer is designed for High Efficiency (HE) detergent use only.
HE detergents are made to produce the right amount of suds and
give the best performance in low water wash systems.
Use only High Efficiency (HE) detergent.
