ON / OFF
Stream Source is designed to remain powered on with mini-
mum consumption for instant access with the Cabasse app.
GREEN POWER LED: Stream Source is active
RED POWER LED: Stream Source is under initialisation or
software update.
DUL POWER LED: Stream Source is not powered and needs
to be connected to the mains.
When you do not use Stream Source, press the (1) key of
the remote control to switch the LEDs off for discretion and
improved energy saving.
USE OF STREAM SOURCE WITH CONTROL
KEYS AND THE STREAM REMOTE CONTROL
1 Control LEDs on/off: available only on the Stream remote
control
2 3 4 VOL "+" and "-", Mute keys: theses functions are
available only when the VOL ON/OFF switch is ON and when
the analog output of Stream Source is being used.
5 and 6 WiFi DLNA source: fast forward and backward wit
5 seconds jump each time a key is being pressed.
Bluetooth source: press to select previous or next track when
playing an album or a playlist.
8 Sources selection: press this key to select the Bluetooth
source ( 9 blue LED) or the WiFi source ( 9 orange LED).
UNPACKING
Open carton flaps; remove all the components. If the spea-
kers or the subwoofer appear damaged, do not use them.
Repack everything in the original packing and contact your
authorised Cabasse dealer immediately. We suggest you to
retain the packing for future use.
SETTING UP
THE COMPONENTS OF YOUR SYSTEM
1 :
1 Stream Source, 1 external power supply with socket
adaptors, 1 optical cable, 1 RCA-RCA stereo audio cable,
1 remote control, 1 manual and one warranty card.
INSTALLATION 5 :
Place Stream Source close to or on the amplifier it will be
connected to.
It should be placed if possible at eyes level for easy vision
of the LEDs, with enough room above it for good WiFi and
Bluetooth transmission and for a smartphone to brush
against the FNC patch for instant Bluetooth connection.
CONNECTION TO THE AMPLIFIER
Use the supplied optical cable if your amplifier is fitted with
a high-end up to date digital to analog converter.
Connect otherwise the analog RCA output of Stream Source
to an analog input (CD, DVD, Tuner, Aux, Tape..) of the
amplifier
Select the appropriate source on the front panel of the
amplifier.
Connection to a power amplifier: use the analog output
when the power amplifier is not fitted with a volume control.
Mount the appropriate male plug on the power supply,
connect the power supply first to the Stream Source then
to the mains. After around 40 seconds initialisation, the
"POWER" LED 1 turns from red to green and Stream
Source is ready to play.
Attention ! The level of the digital outputs being fixed,
only the volume control and the remote control of the ampli-
fier must be used for the adjustment of the sound level
Attention ! the analog output of Stream Source being variable, azd-
just bthe sound level with the Stream remote control and the ""+ and
"-" keys of Stream Source.
If you need the level of the analog output to remain fixed, select the
"OFF" position for the VOL ON/OFF switch on the back of Stream
Source.
CAUtion ! The main plug used to power the system
should remain easy to reach for rapid unplugging of the
device and its external power adaptor.
