POWER™ 1024
PAGE 7
ENGLISH
Chapter 4 : TECHNICAL SPECIFICATIONS
4-1. COMPUTER INPUT (on HD15 female connector).
Line frequency: Up to 48.4 kHz.
Frame frequency: Up to 72 Hz.
FORMATS RESOLUTION LINE FREQUENCY FRAME FREQUENCY
VGA 1 640 x 350 31.5 kHz 70 Hz
VGA 2 640 x 400 31.5 kHz 70 Hz
DOS 720 x 400 31.5 kHz 70 Hz
VGA 3 640 x 480 31.5 kHz 60 Hz
SVGA/VESA 1 800 x 600 35.16 kHz 56 Hz
VESA 5 800 x 600 37.9 kHz 60 Hz
VESA 2 640 x 480 37.9 kHz 72 Hz
VESA 6 800 x 600 47.3 kHz 72 Hz
XGA 1024 x 768 48.4 kHz 60 Hz
Sync. type: Separate H & V sync.
Levels: R, G, B = 0.7 Vp/p.
H & V Sync = TTL.
Impedance: 75 Ohms.
4-2. VIDEO OUTPUTS
• S.VIDEO (on 4-pin mini DIN connector).
Standard on request: PAL: 15.625 kHz / 50 Hz - 625 lines.
or NTSC: 15.735 kHz / 60 Hz - 525 lines.
Levels: Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
C = 0.3 Vp/p (Chroma Burst).
Impedance: 75 Ohms.
• COMPOSITE VIDEO (on BNC connector).
Standard on request: PAL: 15.625 kHz / 50 Hz - 625 lines.
or NTSC: 15.735 kHz / 60 Hz - 525 lines.
Level: Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
Impedance: 75 Ohms.
4-3. ENVIRONMENTAL
Power Supply: External: 250 VAC, 50Hz, 55 mA max.
or 115 VAC, 60Hz, 150 mA max (for US version).
Storage Temperature: - 25 °C to + 85 °C (- 13 °F to + 185 °F).
Operating temperature: 0 °C to 50 °C (32 °F to 122 °F).
Maximum ambient operating temperature: < 40 °C (< 104 °F).
Hygrometry: 10 % to 80 % (without condensation).
Dimensions: D 149 x W 205 x H 49 mm / D 5.86" x W 8.07" x H 1.92".
Weight: 0.9 kg / 2 lbs (with Power supply).
Recognized formats:
