8
Cutout Dimensions - Top View
Back Wall
Side Wall Side Wall
Countertop Front Edge
Cutout (Product Opening) Dimensions
30" (76.2 cm) Models
Models
A B
Minimum Recommended Maximum Minimum Recommended Maximum
KCGS550 and
KCGS950 28 1 ⁄
2
" (72.4 cm) 28 7 ⁄
8
" (73.4 cm) 29 5 ⁄
16
" (74.3 cm) 19 1 ⁄
2
" (49.5 cm) 19 13 ⁄
16
" (50.2 cm) 20"
(50.8 cm)
All Other 30"
(76.2 cm)
Models 28 1 ⁄
2
" (72.4 cm) 28 7 ⁄
8
" (73.4 cm) 29 5 ⁄
16
" (74.3 cm) 19" (48.3 cm) 19 1 ⁄
2
" (49.5 cm) 20"
(50.8 cm)
36" (91.4 cm) Models
KCGS556 and
KCGS956 34 7 ⁄
8
" (88.4 cm) 35 3 ⁄
16
" (89.4 cm) 35 5 ⁄
8
" (90.3 cm) 19 1 ⁄
2
" (49.5 cm) 19 13 ⁄
16
" (50.2 cm) 20"
(50.8 cm)
All Other 36"
(91.4 cm)
Models 33 7 ⁄
8
" (86.0 cm) 34 5 ⁄
16
" (87.0 cm) 35 1 ⁄
4
" (89.5 cm) 19" (48.3 cm) 19 1 ⁄
2
" (49.5 cm) 20"
(50.8 cm)
Side Walls (Combustible Surfaces)
Models H and I
KCGS5 and KCGS9 H and I added together must be at least 48" (122.0 cm), with each side individually being at least
8" (20.3 cm).
KCGS350, KCGS356, MGC9536,
WCG97US0, WCG97US6 H and I added together must be at least 48" (122.0 cm), with each side individually being at least
12" (30.5 cm).
All Other Models Both have to be 8" (20.3 cm) or more.
Back Wall and Countertop Front Dimensions
Models C D E
KCGS550 and KCGS950
25" (63.5 cm) 2 7 /
8
" (7.3 cm)
2 3 /
4
" (6.9 cm)
All Other Models 3 1 /
8
" (7.9 cm)
NOTE: After making the countertop cutout, some installations may require notching down the base cabinet side walls to clear the cooktop
base. To avoid this modification, use a base cabinet with sidewalls wider than the cutout.
If cabinet has a drawer, a 4" (10.2 cm) depth clearance from the countertop to the top of the drawer (or other obstruction) in base cabinet
is required. The drawer depth may need to be shortened to avoid interfering with the regulator.
IMPORTANT: If a built-in wall oven is to be installed below this cooktop, the grounded outlet and gas supply piping must be located in an
adjacent cabinet. If installing a range hood or microwave hood combination above the cooking surface, follow the range hood or
microwave hood combination installation instructions for dimensional clearances above the cooktop surface.
This cooktop and its gas and electrical supply sources must be installed before the undercounter built-in wall oven is installed.
