PL-PRO DMC OWNER’S MANUAL
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Furman does not warrant against damages or defects arising out of improper use or abnormal handling of the product, or against
defects or damages arising from improper installation. This warranty shall be cancelable by Furman at its sole discretion if the product
is modified in any way without written authorization from Furman or Panamax Inc. This warranty also does not apply to products upon
which repairs have been affected or attempted by persons other than pursuant to written authorization by Furman or Panamax Inc.
THIS WARRANTY IS EXCLUSIVE. The sole and exclusive obligation of Furman shall be to repair or replace the defective product in
the manner and for the period provided above. Furman shall not have any other obligation with respect to the products or any part
thereof, whether based on contract, tort, strict liability or otherwise. Under no circumstances, whether based on this Limited Warranty
or otherwise, shall Furman be liable for incidental, special, or consequential damages. This Limited Warranty states the entire obliga-
tion of Furman with respect to the product. If any part of this Limited Warranty is determined to be void or illegal, the remainder shall
remain in full force and effect.
SPECIFICATIONS
CURRENT RATING:
20 amps
OPERATING VOLTAGE:
90 to 139 VAC
OVER VOLTAGE SHUTDOWN:
140 VAC typically
SPIKE PROTECTION MODES:
Line to neutral, zero ground leakage
SPIKE CLAMPING VOLTAGE:
188 VAC peak @ 3,000 Amps, 133 VAC RMS
RESPONSE TIME:
1 nanosecond
MAXIMUM SURGE CURRENT:
6,500 amps
NOISE ATTENUATION:
10 dB @ 10 kHz, 40 dB @ 100 kHz, 50 dB @ 500 kHz
Linear attenuation curve from 0.05 - 100 Ohms line impedance
DIMENSIONS:
1.75” H x 19” W x 10.5” D.
WEIGHT:
12 lbs. (5.5 kg.)
CONSTRUCTION:
Steel chassis, .120” brushed and black anodized aluminum front panel; glass epoxy printed circuit boards
POWER CONSUMPTION:
15 VA
SAFETY AGENCY LISTING:
TUV
