Since the banks are isolated from each other, it is recommended to connect analog equipment into Bank A and digital equipment
into Bank B (or vice versa). The PL-PRO C’s 20 amp (2400 watt) capacity is supplied from a robust 12 AWG, 10 foot AC cord.
Additionally, the PL-PRO DMC offers a switchable laboratory precision digital meter that displays incoming voltage in
1-volt steps or true RMS current in 0.1 amp steps. The voltmeter’s accuracy is ±1.5 volts and features a tri-color voltage range
indicator. This informs the user whether voltage is in or out of a safe range, even from a distance too great to accurately read the
displayed voltage.
SAFETY INFORMATION
To obtain best results from your Furman Classic Series power conditioner, please read this manual carefully before using.
WARNING
To reduce the risk of electrical shock, do not expose this equipment to rain or moisture. Dangerous high voltages are present inside
the enclosure. Do not remove the cover. Refer servicing to qualified personnel only. The lightning flash with an arrowhead symbol
is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
IMPORTANT SAFETY INSTRUCTIONS
(Please read prior to installation)
1. Please read and observe all safety and operating instructions before installing your Furman Classic Series power conditioner.
Retain these instructions for future reference.
2. Your Classic Series conditioner should not be used near water – for example, near a bathtub, washbowl, kitchen sink, laundry tub,
in a wet basement, or near a swimming pool.
3. Do not place your Classic Series conditioner near high heat sources such as radiators, heat registers, stoves, or other appliances
that produce extreme heat.
4. The Furman PL-PRO DMC should only be connected to a 120 VAC, 50Hz/60Hz, 20 amp grounded electrical outlet. Do not defeat
the ground or change polarization of the power plug.
5. Route the AC power cord and other cables so that they are not likely to be walked on, tripped over, or stressed. Pay particular
attention to the condition of the cords and cables at the plugs and at the point where they exit your Furman conditioner. To
prevent risk of fire or injury, damaged cords and cables should be replaced immediately.
6. Clean your Furman conditioner with a damp cloth only. Do not use solvents or abrasive cleaners. Never pour liquid on or into the
unit.
7. Your Furman conditioner should be serviced by qualified service personnel when:
• The power supply cord or the plug has been frayed, kinked, or cut.
• Objects have fallen or liquid has been spilled into the unit.
• The unit has been exposed to rain or extreme moisture.
• The unit does not appear to operate normally.
• The “Protection OK” indicator is not lit.
• The unit has been dropped, or the enclosure has been damaged.
• The retractable LED lights have failed.
8. Your Furman conditioner requires that a safety ground be present for proper operation. Any attempt to operate the unit without
a safety ground is considered improper operation and could invalidate the warranty.
9. Do not attempt to service your Furman conditioner beyond what is described in this manual. All other servicing should be
referred to qualified service personnel.
OPERATION
RETRACTABLE SMOOTH TRACK RACK LIGHTS, REAR PANEL LAMP AND DIMMER CONTROL:
The Furman Classic Series power conditioners utilize a dimmer control for the two retractable Smooth Track light tubes. The dim-
mer knob controls the brightness of both front panel lamps. Turn it clockwise to increase brightness; turn it counterclockwise to
decrease brightness. The knob is also a momentary power switch for the lamps: push it in to turn the lamps on or off. When the
