33
ENGLISH
• Digital Antenna/Satellite
Data 00 : xx (Don’t care)
(Data 01)(Data 02) : Major Channel Number
Data 01 : High byte Channel Data
Data 02 : Low byte Channel Data
- 00 01 ~ 27 0F (Decimal: 1 ~ 9999)
(Data 03)(Data 04) : Minor/Branch Channel Number
(Don’t care in Satellite)
Data 03 : High byte Channel Data
Data 04 : Low byte Channel Data
Data 05 : Input Source (Digital/Satellite for Japan)
- 02 : Antenna TV (DTV)
- 07 : BS (Broadcasting Satellite)
- 08 : CS1 (Communication Satellite 1)
- 09 : CS2 (Communication Satellite 2)
• Tune Command Examples:
1 Tune to the digital antenna (ISDB-T) channel 17-1.
[Set ID] = All = 00
Data 00 = Don’t know Physical = 00
Data 01 & 02 = Major is 17 = 00 11
Data 03 & 04 = Minor/Branch is 1 = 00 01
Data 05 = Digital Antenna TV = 02
Total = ma 00 00 00 11 00 01 02
2 Tune to the BS (ISDB-BS) channel 30.
[Set ID] = All = 00
Data 00 = Don’t know Physical = 00
Data 01 & 02 = Major is 30 = 00 1E
Data 03 & 04 = Don’t Care = 00 00
Data 05 = Digital BS TV = 07
Total = ma 00 00 00 1E 00 00 07
* This feature is varied based on the model.
Ack
(a)( )([Set ID])( )(OK)(Data 00)(Data 01)
(Data 02)(Data 03)(Data 04)(Data 05)
(x)(a)( )([Set ID])( )(NG)(Data 00)(x)
20 [Channel] Control (Command: m b)
► To skip current channel for next time.
Transmission
(m)(b)( )([Set ID])( )(Data)(Cr)
Data 00 : Del(ATSC,ISDB)/Skip(DVB)
Data 01 : Add
Ack
(b)( )([Set ID])( )(OK/NG)(Data)(x)
* Set the saved channel status to del(ATSC, ISDB)/
skip(DVB) or add.
21 Key (Command: m c)
► To send IR remote key code.
Transmission
(m)(c)( )([Set ID])( )(Data)(Cr)
Data : Key code - page 22, 23
Ack
(c)( )([Set ID])( )(OK/NG)(Data)(x)
22 Control [Backlight] (Command: m g)
► To control the backlight.
Transmission
(m)(g)( )([Set ID])( )(Data)(Cr)
Data Min : 00 to Max : 64
Ack
(g)( )([Set ID])( )(OK/NG)(Data)(x)
