30
ENGLISH
13 [Treble] (Command: k r)
(Depending upon model)
► To adjust treble. You can also adjust Treble in the
audio settings.
Transmission
(k)(r)( )([Set ID])( )(Data)(Cr)
Data Min : 00 to Max : 64
Ack
(r)( )([Set ID])( )(OK/NG)(Data)(x)
14 [Bass] (Command: k s)
(Depending upon model)
► To adjust bass. You can also adjust Bass in the
audio settings.
Transmission
(k)(s)( )([Set ID])( )(Data)(Cr)
Data Min : 00 to Max : 64
Ack
(s)( )([Set ID])( )(OK/NG)(Data)(x)
15 [Balance] (Command: k t)
► To adjust balance. You can also adjust balance in
the audio settings.
Transmission
(k)(t)( )([Set ID])( )(Data)(Cr)
Data Min : 00 to Max : 64
Ack
(t)( )([Set ID])( )(OK/NG)(Data)(x)
16 [Color Temperature] (Command: x u)
► To adjust color temperature. You can also adjust
color temperature in the picture settings.
Transmission
(x)(u)( )([Set ID])( )(Data)(Cr)
Data Min : 00 to Max : 64
Ack
(u)( )([Set ID])( )(OK/NG)(Data)(x)
17 [Equalizer] (Command : j v)
► Adjust EQ of the set.
Transmission
(j)(v)( )([Set ID])( )(Data)(Cr)
0 0 0 0 0 0 0 0
MSB
Frequency Data
LSB
7 6 5 Frequency 4 3 2 1 0 Step
0 0 0 1st Band 0 0 0 0 0 0(decimal)
0 0 1 2nd Band 0 0 0 0 1 1(decimal)
0 1 0 3rd Band ... ... ... ... ... ...
0 1 1 4th Band 1 0 0 1 1 19(decimal)
1 0 0 5th Band 1 0 1 0 0 20(decimal)
Ack
(v)( )([Set ID])( )(OK/NG)(Data)(x)
* It depends on model, and can adjust when sound
mode is EQ adjustable value.
18 [Energy Saving] (Command: j q)
(Depending upon model)
► To reduce the power consumption of the TV. You
can also adjust energy saving in picture settings.
Transmission
(j)(q)( )([Set ID])( )(Data)(Cr)
Data 00 : [Off]
Data 01 : [Minimum]
Data 02 : [Medium]
Data 03 : [Maximum]
Data 04 : [Auto]
Data 05 : [Screen off]
Ack
(q)( )([Set ID])( )(OK/NG)(Data)(x)
