WM58106 CAN PARTS LIST
1 2
10
19 20
11 12 14
15 16 17 18
3 4 5 7
8 9
25 26
21 22
23 24
31
29 30
34 32 33
27 28
Pre-installed
Pre-installed Pre-installed Pre-installed
13
6
35 36 37 38
HOME VISITOR
TIME
Board L Tube
2pcs
Board Tube
2pcs
Left Tube
1pc
Right Tube
1pc
Left L Tube
1pc
Right L Tube
1pc
Ramp U Tube
1pc
Allen Key
2pcs
Backboard
1pc
M6 Washer
64pcs
M6 Nut
32pcs
Basketball
4pcs
3.5 x 10mm Bolt
4pcs
4 x 28mm Bolt
2pcs
Lock Pin
2pcs
Wrench
2pcs
M6 x 20mm Bolt
16pcs
M6 x 29mm Bolt
6pcs
M6 x 42mm Bolt
4pcs
M6 x 48mm Bolt
4pcs
M6 x 35mm Bolt
2pcs
Control Box with Wire
1pc
Self-Stick Strap
2pcs
Spring Lock
9pcs
Plastic Pole Insert
2pcs
Electronic Scorer
Face Plate
1pc
Support Tube
2pcs
Mounting Tube
2pcs
Ramp Tube
2pcs
Ramp L Tube
2pcs
Switch Sensor
2pcs
Net
2pcs
Horizontal Tube
2pcs
Ball Return Net
1pc
Electronic Scorer
1pc
Inflation Pump
1pc
Rim Support Plate
2pcs
Rim
2pcs
6
2 1
9 10
13 14
23
27
33
