7
5.4 Sleep setup
At setup state, enter setting of sleep setup by pressing on panel.There are
off,5,15,30,60,90,120 minutes to be selected, and make parameters adjustment
through VOL+/VOL- key on panel.
6. Troubleshooting
Failure solution
1. Display screen is
not bright.
Check whether the socket or power supply connect well.
2. No sound 1）make sure whether the device is connected with power.
2）make sure whether the device is at the working state.
3）make sure whether the device is at pause state or mute.
3. sound distortion
at AUX mode
Make sure that the signal input strength does not exceed
1.1VRMS. (The maximum sound output level of DVD is 2VRMS.
So when DVD player is used as external sound input resources,
don’t turn up the volume to maximum position. ）
7. Specification
Items Content
Adapter input 110-240V 1A 50/60Hz
Adapter output DC 9V-2A
Power dissipation 12W
Standby Power
dissipation
Less than 1W
Power of speaker 2X2W
SNR 70 dB
Frequency response 20Hz～20KHz
Input sensitivity Line in:1.1Vrms;IPHONE:900mVrms;
SNR 50 dB
FM
Sensitivity 1 dBuV
Size 196x95x75mm
Weight 600g
8. Recycling
This product bears the selective sorting symbol for waste electrical and electronic equipment.
This means that this product must be handled pursuant to European Directive 2002/96/EC in
order to be recycled or dismantled to minimize its impact on the environment. Note:
Electronic products not included in the selective sorting process are potentially dangerous for
the environment and human heath due to the presence of hazardous substances.
