Installation Guide
Press MENU button to display the MAIN OSD MENU; Press Ż / Źbutton to select the
MENU you want; Press ENTER button to enter the sub menu; Press ź / Ÿ button to select the
option and then press Ż / Ź to adjust the value in the sub menu; You can press MENU button to
go back to the upper menu or EXIT button to close the OSD.
You can select the type of picture, which best corresponds to your viewing. Press the “MENU”
button to enter the OSD menu .Then
press “
e/f” button to select the
“PICTURE” menu.
1. Press “ d” button to select “Picture
Mode”, press “ e/f” button to select.
2. Press “ c/d” button to select
“Brightness” and press the “ e/f”
button to enter brightness adjustment
menu to adjust brightness.
3. Press “
c/d” button to select
“Contrast” and press the “ e/f” button
to enter contrast adjustment menu to
adjust contrast.
4. Press “
c/d” button to select “Color” and press the “e/f” button to enter color adjustment
menu to adjust color.
5. Press “ c/d” button to select “Tint” and press the “e/f” button to enter hue adjustment menu
to adjust tint.
Note: The 'Tint' item is used in NTSC mode only.
6. Press “ c/d” button to select “Sharpness” and press the “e/f” button to enter sharpness
adjustment menu to adjust sharpness.
7. Press “ c/d” button to select “Color Temperature” and press the “e/f” button to select.
8. Press “ c/d” button to select “Advanced Setting” and press the “ENTER/f” button to enter
sub-menu.
