5
Introduction
Introduction
(IR) Infrared Receiver: Receives Infrared signals from the remote control.
1).(Power on/Standby)LED Indicator: Press POWER button to turn on or off.
Indicator off(Red) Standby mode
Indicator on(Blue) Power on mode
2). The functions of the buttons:
INPUT: Press to display the input source menu.
MENU: Press to display the OSD menu,
press again to exit the menu.
: Press to scan through channels.
VOL+/-: Press to adjust the sound volume.
POWER: Turn on/standby the TV set.
The effective receiving range for the signal is 5-8 metres from the front of the remote
control window, and 30
0
to the left or right side and 20
0
above or below the remote control
window.
Press INPUT button on the TV set or SOURCE button on
the remote control to display the input source menu, and
use
button on the TV set or button on
remote control to select the input source, press OK button
on the remote control to enter.
Note: Before you select the input source, make sure the
connections are prepared.
Power Indicator
Remote Control window (Keep clear)
/
/
1 、Front View
