1.0 introduction
The electronic control system on the Vido provides a wide range of options that can be
selected according to system complexity and operating requirements.
The unit is factory set to ‘Easy Mode’ giving thermostatic temperature control, fan only
option and clock function.
2.0 display
/ 11
1. Heating indicator
2. Cooling indicator
3. Temperature symbol
when this is displayed the
current room temperature
is displayed
4. Fan speed symbol
(fan blades will rotate when active)
5. Comfort setting
6. Power (on/off)
7. Clock setting
8. Room temperature
9. Time
10. Day of the week
11. Square indicator highlights the selected function
3.0 operation
Use or keys to choose from the following options, the function is highlighted when
a appears over the icon.
Comfort setting :
The Vido will run indefinitely in this setting, providing the water temperature is greater
than 32°C heating, less than 15°C cooling. The fan speed will automatically switch
depending on the difference between the room temperature and the required set
temperature.
Use the (+) and (-) keys to set your desired temperature, followed by (OK) to confirm.
(Default setting is 21°C).
Setting fixed fan speed function :
Selecting one of these options provides fan only operation with no temperature control.
Using the (+) and (-) keys select F1, F2, or F3 for your desired fan speed (F1 being the
lowest fan speed and F3 the highest), followed by (OK) to confirm.
Setting clock and day function :
Using the and keys tab across to to allow you to set the clock and/or day function
then press (OK) to change the time.
To set the minutes use the (+) and (-) keys, followed by (OK) to confirm.
To set the hours use the (+) and (-) keys, followed by (OK) to confirm.
To set the day use the (+) and (-) keys, followed by (OK) to confirm.
