CONTROL PANEL & FEATURES
TEMPERATURE
Select a drying temperature based on the fabrics in your
load. If you are unsure of the temperature to select for a
load, select the lower setting rather than the higher setting.
SIGNAL
The Signal produces an audible sound when the drying cycle
is finished. Promptly removing clothes at the end of the cycle
reduces wrinkling.
Turn the SIGNAL knob to select the desired setting (Off,
Low, or High).
CYCLE KNOB
Use Cycle Knob to select available cycles on your dryer.
Turn the knob to select a cycle for your laundry load. See
“Cycle Guide” for detailed descriptions of cycles.
TIMED DRY
Will run the dryer for the specified time on the control.
On models with a selectable temperature knob, you
may choose a setting based on the fabrics in your load.
On some models, temperature is included in the cycle
selections. Drying time and temperature will depend on
your dryer model.
SENSOR DRY
Senses moisture in the load or air temperature and shuts
off when the load reaches the selected dryness level.
Gives the best drying in the shortest time. Drying time
will vary based on fabric type, load size, and temperature
setting.
1
2
5
WRINKLE CONTROL Feature
The WRINKLE CONTROL feature will run after your drying
cycle is complete. It periodically starts and stops the dryer,
tumbling the load without heat to help avoid wrinkling.
WRINKLE CONTROL automatically starts at the end of the
cycle. Opening the door will stop this feature.
n Get up to 120 minutes of heat-free, periodic tumbling at
the end of a cycle. Turn the WRINKLE CONTROL knob
to OFF, 60 min., or 120 min. at any time before the cycle
has ended.
NOTE: A signal will sound periodically when the WRINKLE
CONTROL setting is selected, but only if the Signal is also
selected.
PUSH TO START
Press the PUSH TO START knob to start the dryer.
Not all features and options are available on all models.
Appearance may vary.
5 2 3 4 1
3
4
