Manuel d’utilisation de la Cybex
Avertissements et mises en garde
Les autocollants d’avertissement indiquent une situation potentiellement dangereuse qui peut
entraîner des blessures graves, voire mortelles si les mesures de sécurité ne sont pas respectées.
Les autocollants de mise en garde signalent une situation potentiellement dangereuse qui, si elle
n’est pas évitée, risque d’entraîner des blessures mineures ou moyennement graves.
Les schémas figurant après les autocollants indiquent l’emplacement de chaque autocollant.
