ADJUSTING THE THROTTLE CABLE
Make sure the throttle cable is adjusted properly. To adjust throttle cable, rotate adjustment
nut located at the hand throttle.
Check if the throttle twist grip has the required free operating movement.
The required free operating movement: 2-6mm (.078 -.24in) . If the grip cannot be moved
freely, turn the adjusting nut to ensure proper operating movement.
After adjustment, start the engine and check for the operating movement again. Repeat the
adjustment if necessary until the desired operating movement is obtained.
ADJUSTING THE CARBURETOR
Adjusting procedures of idling speed:
1. Support the vehicle by a stand.
2. Adjust the idle speed by the throttle stop screw to 1400 +200 RPM
-150.
CAUTION
Do not try to correct a malfunctioning carburetor by adjusting the idling speed. If the
carburetor is not functioning properly, it should be repaired by a service center.
Adjust idling speed only when the engine is warmed up or 10 minutes after operation.

Throttle cable adjust nut
