CHECkING & CLEANING THE AIR FILTER
CAUTION
The air filter element must be intact or the engine will suck in dust and dirt, resulting in a
shorter service life of the engine.
Water should be prevented from entering into the filter when washing the vehicle.
The filter element shall be cleaned gently without twisting to prevent it from cracking.
Never wash it with gasoline or any acid, alkaline or organic volatile oil to avoid its aging,
which will result in reducing the effect of the air filter oil to catch particles before they
enter the engine. Replace the filter element with a new one if it is broken or cracked.

Air Filter box
Removal of filter
Removal of cover
Rinse with fresh water then
queeze out excess.
Wash with mild soap
and water
1. Remove seat to access air filter. Seat is removed by
removing nut located under seat (see photo).
2. Locate Air Filter Box under seat and remove cover.
3. Remove air filter.
4. Remove foam cover from Air filter element.
5. Tap the Air filter element gently to remove most of the dust
and dirt. Blow out remaining dust with compressed air. If
the element is damaged, replace it.
6. Wash the foam element cover per instructions below then
allow to dry thouroghly.
7. Reinstall foam cover to the air filter element.
8. Reinstall air filter and close cover.
Air filter element
Foam cover Air Filter
Seat nut
