Sony CDX-GT710 - Manuel (Page 14)

14
F:\Data Disc\2898876221\289887622CDXGT710U\01US02CD-U.fm masterpage:Left
CDX-GT710/GT71W
2-898-876- 22 (1)
Skipping albums and discs
1 During playback, press (3) / (4) (GP/ALBM –
/+).
Repeat and shuffle play
1 During playback, press (1) (REP) or (2)
(SHUF) repeatedly until the desired setting
appears.
*1 When one or more CD/MD changers are
connected.
*2 When one or more CD changers, or two or more
MD changers are connected.
To return to normal play mode, select “Repeat
off” or “Shuffle off.”
Tip
“SHUF ALL” will not shuffle tracks between CD units
and MD changers.
Locating a disc by name — LIST
You can select a disc from the list when a CD
changer with CD TEXT capability, or MD
changer is connected.
If you assign a name to a disc, the name appears
on the list.
1 During playback, press (LIST) .
The disc number or disc name appears.
2 Rotate the volume control dial until the desired
disc appears.
3 Press (ENTER) to play the disc.
The display returns to normal play mode.
With the card remote commander
In step 2: press M or m instead of the volume control
dial.
Rotary commander RM-X4S
Attaching the label
Attach the indication label depending on how
you mount the rotary commander.
Location of controls
The corresponding buttons on the rotary
commander control the same functions as those
on this unit.
The following controls on the rotary commander
require a different operation from the unit.
• PRESET/DISC control
The same as (GP/ALBM) –/+ on the unit (push
in and rotate).
• VOL (volume) control
The same as the volume control dial on the unit
(rotate).
• SEEK/AMS control
The same as (SEEK) –/+ on the unit (rotate, or
rotate and hold).
Changing the operative direction
The operative direction of the controls is factory-
set as shown below.
If you need to mount the rotary commander on
the right hand side of the steering column, you
can reverse the operative direction.
To skip
Press (3) / (4) (GP/ALBM –/
+)
album and release (hold for a
moment).
album
continuously within 2 seconds of first
releasing.
discs repeatedly.
discs
continuously then, press again within 2
seconds and hold.
Select To play
Repeat Disc * 1 disc repeatedly.
Shuffle
Changer
* 1
tracks in the changer in random
order.
Shuffle All * 2 tracks in all units in random
order.
SOUND
DSPL
MODE
SOUND
DSPL
MODE
OFF
ATT
SOUND
SOURCE
DSPL
MODE
OFF VOL SEEK/AMS
PRESET/
DISC
To increase
To decrease
