Motorola Talkabout T110 Alkaline Two-Way Radio (3-Pack, Green/Blue/Orange and White) - Manuel (Page 15)

13
English
• When the "Leader’s radio" does not have sub-code
feature, all "Members’ radios" will have their sub-code
set to zero (Disable). When a radio sub-code is set to
zero, all transmissions received on the channel will be
sent to the speaker, regardless of the sub-code
embedded in the transmission.
• Your radio does not have sub-code feature and is not
compatible with radios with sub-code enabled. Please
ensure all radios in the group have their sub-code
disabled (Sub-code is set to Zero). With Easy pairing,
either use your radio as the leader, or ask the Leader
to set sub-code to zero before performing easy
pairing.
Channels and Frequencies
Note: The power refers to the maximum allowable power
defined by FCC/ISED for each channel under FRS
rules for USA and FRS/GMRS for Canada, and is not
a reflection of the power specification of the radio.
Table 1: USA, Canada, Mexico, Panama,
Paraguay, and Uruguay
Channel Frequency
Max Power
Output
1 462.5625 MHz 2 W
2 462.5875 MHz 2 W
3 462.6125 MHz 2 W
4 462.6375 MHz 2 W
5 462.6625 MHz 2 W
6 462.6875 MHz 2 W
7 462.7125 MHz 2 W
8 467.5625 MHz 0.5 W
9 467.5875 MHz 0.5 W
10 467.6125 MHz 0.5 W
11 467.6375 MHz 0.5 W
12 467.6625 MHz 0.5 W
13 467.6875 MHz 0.5 W
14 467.7125 MHz 0.5 W
15 462.5500 MHz 2 W
16 462.5750 MHz 2 W
17 462.6000 MHz 2 W
T11X.book Page 13 Wednesday, December 16, 2020 11:13 PM
