9
En
En
glish
Interface
Front/Top view
1 Eject Button ( h )
Press to eject a disc.
* If this device is connected to Mac, you will not be able
to use this function due to the specifications of macOS.
2 Disc Loading Slot
Insert disc (only a BD, DVD or CD) slowly; when
inserted a certain distance, the disc will automatically
be pulled into the drive.
The disc should be inserted flatly, parallel with the
surface of the drive.
Do not insert objects other than specified discs into the
loading slot.
1 2
In the case of vertical installation
If the device is installed vertically, be sure to use the stand
and rubber cushion provided as accessories.
Insert the drive right till the end of the stand.
5 mm 20 mm
Installation of the stand and pasting of the rubber cushion (recommended example)
If you do not paste a rubber cushion, the vibrations could result
in noise and poor operation.
Rubber cushion
