Connection
This is a hot-plug unit. Connect the unit to the supplied USB cable.
1 Confirm that your computer (PC) has available USB port.
2 With your Windows® or Mac operating system running, use the supplied USB cable to connect
this unit to the PC.
Caution
• Do not disconnect the USB cable during data transfers.
• Do not disconnect the USB cable during the PC start nor any operation with the unit.
Note
• It is recommended to connect to USB 3.0 port or above, since when a USB 3.0 cable is connected
to a USB 2.0 port, the connection will be limited to USB 2.0 performance standards.
• This unit can operate with USB 1.1 but will not provide optimum performance.
• Connecting this unit through a USB HUB or using unspecified cables may not guarantee proper
operation.
• If power is insufficient when using a USB port, connect an AC adapter (not included) through the
DC IN connector on the unit’s rear panel and plug into a wall outlet to deliver power. Connect the
USB cable (included) after connecting the AC adapter for proper operation. For more details about
the AC adapter connection, visit or contact
https://www.pioneerelectronics.com/PUSA/
Phone: 1-800-421-1404
• Do not connect any AC adapter other than specified by Pioneer.
This unit is for use only with compatible UL Listed personal computers that have Installation
Instructions detailing user installation of USB accessories.
UL Listed, Class 2 AC Adapter (Output 5 V, min. 1.0 A) shall be used.
Computer
(PC)
USB Type-C or USB Standard A
(USB 3.0 or above is
recommended)
This unit
USB cable (supplied)
