GENERAL DESCRIPTION
The RG-65 is a unique, easy-to-operate tester, designed for testing
glass-break detectors.When used in conjuction with the VITRON
glass-break detector, it eliminates the need to open the detector
for testing. This sophisticated tester can generate several different
audio sounds for testing the most comprehensive range of existing
glass types.
CODE - an Audible Coded Message is transmitted which puts the
VITRON into Test Mode.
GLASS - a real glass-breaking sound is released, according to the
position of the type-of-glass switch.
Determines the type of sound the VITRON tester will emit. TM
- selects the type of glass-breaking sound (for most commonly
used glass types)
3. LAMINATED/WIRED, TEMPERED & PLATE
WARNING : The RG-65 produces loud sounds. Therefore, always
point it away from someone's ear when used at close range.
MANUAL - momentary position - generates a sound each time
the switch is pressed.
AUTO - latched position - the VITRON tester will
continuously repeat the sound, followed by a
4 seconds pause. Use this position to check the
VITRON's optimal mounting location. (The RG-65 is
fixed near the window, while the VITRON isportable).
Note: In order to save battery-life, turn the switch
to OFF after operation.
1. MANUAL/OFF/AUTO
Activates the VITRON tester. TM
2. CODE/GLASS
TM
OPERATIONAL SWITCHES
The VITRON tester has 3 switches: TM
TESTING THE VITRON: Lasts for two minutes
The RG-65 allows a unique shortcut for testing the VITRON,
without having to open up the detector.
Using an Audible Coded Message, the RG-65 remotely sets the
VITRON toTest MODE, as described below:
a. Aim the RG-65 towards the VITRON (line-of-sight) and generate
an Audible Coded Message:
1. Set the lower slide switch to "CODE"
2. Press on "MANUAL".
b. Verify that the VITRON enters Test Mode. (The LED blinks once
every 2 seconds).
c. Hold the simulator with its back side close to the furthest point of
the protected glass while facing the VITRON glass-break detector.
Note: If the protected glass is covered by curtains, blinds,
etc.., hold the tester behind them (worst conditions).
d. Generate a glass breaking sound:
1. Set the lower slide switch to "GLASS"
2. Set the upper silde switch to the desired type of glass.
3. Press to "MANUAL" or "AUTO" position.
e. Verify that the VITRON detector enters ALARM Mode .
(The LED lights for 2 seconds and alarm relay is activated).
NOTE: With VITRON in Test Mode, setting CODE switch and
pressing "MANUAL" will extend Test Mode by another
2 minutes.
TESTER LED INDICATION
If the TESTING LED doesn't light during activation, replace the battery
SPECIFICATIONS
ELECTRICAL
Operating voltage: 9V alkaline battery
Battery life: approx.2800 operations (MANUAL
mode)
PHYSICAL
Size: 219X103X29 mm (8.5x4x1.1 inch)
SIMULATED GLASS-BREAKS
Types: Plate, laminated, wired & tempered.
ENVIRONMENTAL
Operating temperature: 0 o C - 55 o C (32 o F - 131 o F)
Storage temperature: -20 o C - 60 o C (4 o F - 140 o F)
In order to continue improving its product, RISCO Group reserves
the right to change specifications and/or designs without any prior
notice.
09/08 RISCO Group 5IN65ML B
