FIG.5
8. Attach the Horizontal Tube (#12) to the Board Tube (#2) using
Bolts(#24), Washers(#22) and Nuts(#27). And then insert the
Board L Tubes (#1) to the Board Tube (#2).
FIG. 5
6
27
x2
x4 22
24 x2 27
x1 x2 1 12
2
2
1
7
12
12
22
24
