ASSEMBLY INSTRUCTIONS
FIG.1
Find a clean, level place to begin the assembly of your
Basketball Game. We recommend that two adults work
together to assembly this basketball game.
Remove all the parts from the box and verify that you have
all of the listed parts as shown on the Parts List
below.Carefully cut or tear the four corners of the box so
that the bottom of the box can be used as your work
surface.
3. Attach the Board Tubes (#2) to the Left Tubes (#3) and
Right Tubes( #4) using spring lock.
FIG.2
4. Attach the Support Tubes (#7) to the Mounting Tubes (#8)
using spring lock.
x1 x2 2
1
2
3
x2 7 x2 8
x1 4
FIG. 1 FIG. 2
Spring
Lock
Spring
Lock
2
2
4
8 8
7
7
3
