Livarno 102631-14-01 - Manuel (Page 8)

8 GB/IE
be located between the diode 14 and the
light.
The lamp 1 will now light up white.
Operation
Select a light colour or different colour change
effects using the remote control
2 (Fig. A):
Selecting the light colour
Press one of the colour buttons 12 or the
W button 7 to select a light colour corre-
sponding with the button.
Press the button 3 to gradually increase
the light intensity.
Press the button 4 to gradually reduce
the light intensity.
There are 5 brightness settings to choose
from.
Colour change selection
FLASH: Press the FLASH button 8 to
select a colour change pattern alternating
between the basic colours red, green and
blue (RGB).
STROBE: Press the STROBE button 9 to
select a sophisticated colour change program:
- white light flashes 6 times, then ...
- RGB light colours alternate with a „rough“
transition, then ...
- 7-colour change with a „rough“ transition,
then ...
- RGB light colours change with a „soft“
transition, then ...
- 7-colour change with a „soft“ transition.
FADE: Press the FADE button 10 to gener-
ate a colour change between 7 colours and
a „soft“ transition.
SMOOTH: Press the SMOOTH button 11
to generate a colour change between
7 colours and a „rough“ transition.
Repeatedly press the button 3 to grad-
ually increase the speed of the respective
colour change.
Repeatedly press the button 4 to grad-
ually reduce the speed of the respective col-
our change.
There are 5 speeds to choose from.
Activating the respective colour change
automatically selects medium speed.
