RADIO OPERATION
1.
Set the Function Selector to the RADIO position.
2. Slide the Band Switch to the "AM" or "FM" position.
3. Turn the Tuning Knob to your desired radio station.
4. Adjust the sound level by rotating the Volume Control Knob.
ANTENNA
For best reception, fully extend the FM Antenna to receive FM stations. For AM reception, the unit has a
built-in antenna, turn the whole unit for best reception.
CD FUNCTION
To play a CD, please follow the steps underneath:
1.
Set the Function Selector to the CD position;
2. Open the CD door, Insert the CD with the printed side facing up and close the CD door;
3. Disc information (total number of tracks) will appear on the LED display;
4. Press Play/Pause button to start playing the CD;
5. Adjust the volume control to the desired volume level;
6. Press Stop, to stop playing the CD.
Skip Mode
1.
During play or pause mode, if Skip Button is pressed, it will go to next track and display the track
no. and then continue play or pause mode.
2. During play or pause mode, if Skip Button is pressed, it will go back to the beginning of the track,
same track no. is display and CD continue the play or pause mode.
3. After step 2, press Skip Button again, it will go to the previous track and continue the play or
pause mode.
Programming the CD Player
The programming of the CD player should be done during STOP mode.
1. Press the PROGRAM button to begin programming the CD player;
2. Press
Skip or Skip buttons, to select desired track;
3. Once the number of the desired track appears in the display, press PROGRAM button again to store
this track in memory;
4. Repeat steps from 2 to 3 to store more tracks in memory. You can store a maximum of 20 tracks in
the memory.
5. Press PLAY/PAUSE button to play the disc in the programmed order;
6. To stop playing, press STOP;
7. To cancel the programming, press STOP button and open the CD player door or select a different
function mode (AUX/OFF or RADIO)
Repeat Mode
Repeat 1: When the Repeat Button is pressed once, the Repeat LED Indicator will light and flash
continuously. This single track will be repeated.
Repeat All: When the Repeat Button is pressed twice, the Repeat LED Indicator will stay lighted. The
whole disc will be played continuously.
To Cancel Repeat Function: Press the Repeat Button until the lighted Repeat LED Indicator turned off.
- EN 4 -
MP3/AUX IN CONNECTION
1.
Insert the audio cable (requires 3.5mm stereo plug, not supplied) into the Line Out Jack or Phones
Jack on your MP3 Player into the corresponding AUX Input Jack on your main unit.
2. Slide the Function Selector to AUX/OFF position.
3. Make sure your AUX in component is turned on, and follow your component’s instruction.
4. To stop this function, simply turned off the component.
CARE AND MAINTENANCE
Precautions
1.
Always turn off the unit after use.
2. Keep the unit away from magnetic objects, water or heat sources.
3. Use a clean soft cloth moistened with lukewarm water to clean the cabinet. Never use chemical
cleaners that could damage the finish of the unit.
4. Never touch the CD pickup and lens. If fingerprints get on the pickup lens, clean it gently with a
commercial lens cleaner.
5. Disconnect the unit from any power sources before cleaning.
NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
y
Reorient or relocate the receiving antenna.
y Increase the separation between the equipment and receiver.
y Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
y Consult the dealer or an experienced radio/TV technician for help.
SPECIFICATIONS
Frequency Range:
AM 530 - 1710 KHz
FM 88 - 108 MHz
Power Supply: AC 120V ~ 60Hz
DC 9V (6 “C” size batteries)
Specifications are subject to change without further notice.
- EN 5 -
