CONNECTING THE UNIT TO POWER
Plug one end of the AC adaptor into the DC jack, and then plug the other end into AC wall
outlet. Before switching on the unit, make sure that the voltage of your electricity supply is the
same as that indicated on the rating plate.
BATTERY BACKUP
Insert two (2) piece UM-4 batteries (not included) into the battery compartment. Be sure to
observe the proper polarity (the "+" and "-" signs) as indicated inside the battery
compartment.
In case of power failure or interrupted AC power, the current time and alarm time settings, the
stored radio stations are preserved in the memory of the unit by means of battery back-up
function.
SETTING THE CLOCK
1.
With the unit powered off, press and hold the CLK/MEM button. The time will begin to
flash on the LED display.
2. Press the HOUR/ button to adjust the hour.
3. Press the MIN/ button to adjust the minute.
4. When the correct time is selected, press the CLK/MEM button again to confirm.
SETTING THE ALARMS
1.
With the unit powered off, press and hold the AL1/VOL + or the AL2/VOL− button. The
alarm time will begin to flash on the LED display.
2. Press the HOUR/ button to adjust the desired alarm hour.
3. Press the MIN/ button to adjust the desired alarm minute.
4. When the desired alarm time is selected, press the AL1//VOL + or AL2/VOL− button to
confirm.
5. Press the AL1/VOL + or AL2/VOL− to select the ALARM sound mode - buzzer or
currently set radio station.
SNOOZE FUNCTION
1.
Whenever the alarm (radio or buzzer) comes on, it can be temporarily suspended for a
short period of 9 minutes by pressing the SNOOZE/SLEEP button once.
2. The buzzer or radio will then automatically come on again after the 9 minutes ‘Snooze’
period has ended.
3. This procedure can be repeated for up to approximately one hour.
LISTENING TO THE FM RADIO
1.
Press the SOURCE/AL.OFF button to select AM or FM band..
2. Press the HOUR/ or MIN/ button step by step to tune to the desired radio stations.
3. Press and hold the HOUR/ or MIN/ button for approx. 1 second, it will start to
search the next radio station in the direction of the search. The search operation simply
finds stations with strong signals. Stations with weak reception can only be tuned in
manually.
SAVING A RADIO STATION TO THE MEMORY
1.
Tune to the desired radio station.
2. Press the CLK/MEM button for approx. 2 second, the LED display will show P01 and
flash, you can press the HOUR/ or MIN/ key for desire channel and then press
CLK/MEM button to confirm.
3. Up to 10 FM & 10 AM radio stations can be stored in the memory.
TO LISTEN TO A SAVED RADIO STATION
Press the CLK/MEM button to skip to the next stored radio station.
SLEEP TO MUSIC FUNCTION
1.
This function allows you to listen to the radio while you fall asleep.
2. Press the SNOOZE/SLEEP button, the display will show the default sleep time of 90
minutes
3. Press the SNOOZE/SLEEP button again to select the desired sleep time, when the
desired SLEEP time is reached, stop pressing the SNOOZE/SLEEP button, the sleep
time will store in the memory after few seconds..
4. The options are 90-80-70-60-50-40-30-20-10-min. or OFF
5. Now you can enjoy listening to the radio for the pre-set period of sleep time.
6. After this pre-set time has elapsed, the unit will switch off automatically.
TURN OFF THE RADIO
Press and hold the SOURCE/AL OFF button for approximate 1 second, the radio will turn off.
SPECIFICATIONS
Frequency Range:
FM 87.5 – 108 MHz
AM 530 – 1710 KHz
Power requirements :
AC-DC Adaptor :
Input : AC 120 V ~ 60 Hz
Main Unit : DC input : DC6V 200mA
Back-Up Battery for clock: 2 pc. UM4 ‘AAA’ size Batteries (not included)
AC power consumption: 4Watts.
Specifications are subject to change without prior notice.
