Curtis SP288 - Manuel (Page 7)

6
POWER SOURCE
Inert the AC/DC adapter plug into a conveniently located AC outlet having AC 120V~60Hz.
WARNING: This unit has a long cord that can easily be tripped on or pulled
on, causing injury. Please make sure it is arranged so it will not drape over a
tabletop, etc. where it can be pulled on by children or tripped over accidentally.
GENERAL OPERATION
1. Press button to turn on or turn off the unit.
2. Press the MODE button repeatedly to select the playback source. The source
Note: If no USB device or CARD was inserted, USB or CARD mode cannot
be selected by MODE button.
3. Press the VOL(Volume)+/- Buttons to adjust volume level.
4. Press the EQ button to set EQ (equalizers) mode as desired.
5. Press the Button on the remote control to turn o ff the sound. Press it again
to turn it back.
6. If the unit is not used for a long period of time, pull out the plug to turn off the
unit completely.
PLAY RADIO
Press the button to turn on the unit.
1. Press button repeatedly until the FM Indicator turns green.
stations then stored into the memory automatically.
3. After finished FM SCAN, press numeric buttons then wait for approx 3
seconds, you can select 1-20 preset stations. eg: pressing “1”, means preset
station 1. pressing “2” + “0” means preset station 20. Or press to cycle through
To enhance radio reception ability:
FM: Fully unwind the antenna wire. Extend the antenna wire and place it in the
indicator will light green accordingly.
MODE
and listen to the preset stations.
all available
the FM SCAN button or press and hold button and then the unit will start
to search
LISTENING TO AUXILIARY SOURCE
1. Connect your auxiliary source (e.g. iPod / iPad / MP3 player) to the AUX jack.
2. Press button to turn on the unit.Press the
Button repeatedly until
the AUX indicator turns green.
3. Start playback from your auxiliary source.
4. Adjust the volume to desired level.
5. To stop playback, disconnect your auxiliary source from the AUX jack.
MODE
WARNING:
Note:
2. Press
