Curtis SP288 - Manuel (Page 6)

5
REMOTE CONTROL
1. STANDBY Button
2. (TUNE -) Button
3. VOL (Volume)+/- Buttons
4. MODE Button
5. (MUTE) Button
6. (TUNE+) Button
7. (Play/Pause) Button
8. STOP Button
9. FM SCAN Button
10. EQ Button
1
MODE
1 2 3
6
9 8
5 4
7
0
SCAN
FM
PREV NEXT PLAY/PAUSE
VOL+ VOL -
1
2
3
4
5
6
7
8
9
10
11
E Q
“1” “2” “3”
The remote control operates on 1pc “CR2025” lithium battery
(included). To power up the remote control, remove the insulation
tab from the back of unit.
Replacing battery for the remote control
1. Push and slide out the battery door.
2. Replace the battery with a new CR2025 button cell with the polarity “+” facing up.
3. Slide the cover back.
Notes on batteries
• Never recharge the batteries, apply heat to them or take them apart.
• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
• Do not throw the batteries in fire!
• Attention should be drawn to the environmental aspects of battery disposal.
• If the remote control is not going to be used for a long time, remove the battery
to avoid damage caused by battery leakage corrosion.
• Please respect the environment. Before throwing any batteries away, consult
your distributor who may be able to take them back for specific recycling.
CAUTION:
Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type.
LOCATION AND DESCRIPTION OF CONTROLS
1. Numeric Buttons
