8
OPERATING YOUR APPLIANCE
 Temperature Control Panels
Refrigerator Temperature Control Freezer Temperature Control
 Setting the Temperature Control
Your refrigerator has a separate control for regulating the temperature for each section independently.
The temperature control is located at the rear of each section (refrigerator / freezer). (See the graphics
shown above).
 The first time you turn the unit on, set the temperature control to “COLD” in refrigerator section and
“COLD” in freezer section.
 The range of the temperature controls are from position “WARM” to “COLD” the coldest in
refrigerator section and from position “WARM” the warmest to “COLD” the coldest. After 24 to 48
hours, adjust the temperature control to the setting that best suits your needs. The setting of “MED”
in freezer section and the mid range marked “
●”
between “WARM” and “COLD” in refrigerator
section should be correct for home or office refrigerator use.
NOTE:
AMBIENT TEMPERATURES BELOW 50ºF (10ºC) WILL AFFECT THE OPERATION OF YOUR
REFRIGERATOR. WHEN THE UNIT IS PLACED IN AN AREA WHERE THE TEMPERATURE
DROPS LOWER THAN 50ºF (10ºC), SET THE TEMPERATURE CONTROLS SELECTORS TO “MAX”
IN BOTH THE REFRIGERATOR AND FREEZER SECTIONS.
NOTE:
 IF THE UNIT IS UNPLUGGED, HAS LOST POWER, OR IS TURNED OFF, YOU MUST WAIT 3
TO 5 MINUTES BEFORE RESTARTING THE UNIT. IF YOU ATTEMPT TO RESTART BEFORE
THIS TIME DELAY, THE REFRIGERATOR-FREEZER WILL NOT START.
 Using Your Ice Cube Tray
 Recommended thermostat setting for ice making is position “COLD”.
 Fill the ice cube tray (two thirds of it) with cold water or with any liquid suitable
for freezing and place the tray on the bottom of the freezer to freeze properly.
 Dry the tray, otherwise it may stick to the bottom of the freezer.
 The best method to get ice cubes out of the tray is to hold the tray under cold
tap water for a second.
 To eject the ice cubes from the tray, place over the ice bucket and twist
slightly
