Curtis FRW183 - Manuel (Page 14)

VII Operating Your Thermoelectric Cellar
It is recommended that you installed the thermoelectric cellar in a place where the ambient
temperature is between 16-32°C. If the ambient temperature is above or below
recommended temperatures, the performance of the unit may be affected. For example,
placing in extreme cold or hot conditions may cause interior temperature to fluctuate. The
range of 7-18°C (44-64°F )may not be reached.
The temperature may fluctuate depending on whether or not the interior light is on or off or
whether the products are located on the upper, middle or lower section.
How to set temperature:
This is a duel zones thermoelectric cellar, there are six touch-buttons on the control panel:
• When you are facing the thermoelectric cellar, the keys on your left are to control the
upper zone, and keys on your right are to control the lower zone.
• “ ” and “ ” increases or decreases the set temperature by 1°C (temp range is
7-18°C for upper zone and 11-18°C for lower zone).
• “ ” button turns on or off the interior light.
Note:
• This product is designed for maximum cooling of 15°C below ambient temperature.
• When the ambient temperature is 21°C or less, unit is capable of maintaining a set
temperature range between 7-18°C.
• When the ambient temperature around 25°C or less, unit can maintain a
temperature range between 11-18°C.
VIII Care And Maintenance
Cleaning your thermoelectric cellar
z Unplug the thermoelectric cellar and remove your products inside.
z Wash the inside with a warm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
z The outside of thermoelectric cellar should be cleaned with mild detergent and warm
water.
z Draw out the water box at the bottom, and wash.
Moving your thermoelectric cellar
z Remove all the items inside.
