A. Features:
5 - 1000 MHz (1 GHz) - Bi-Directional Splitter.
Auto-seizing F port connectors
6 kV ring wave surge protected for high surge resistance
Digital cable and HDTV approved by most major cable operators
Low intermodulation and 40 dB port-to-port return band isolation
B. Specifications:
Frequency Insertion Loss Isolation Input Return Loss Output Return Loss
5-14 MHz 6.8/9.0/10.8dB 25/25/25dB 22/22/22dB 22/22/22dB
14-40 MHz 6.8/9.0/10.8dB 40/35/40dB 22/22/25dB 38/30/35dB
40-200 MHz 7.0/9.2/10.8dB 35/28/35dB 22/22/22dB 28/25/28dB
200-550 MHz 7.2/9.4/11.0dB 28/26/28dB 22/22/22dB 25/22/25dB
550-750 MHz 7.4/9.6/11.2dB 26/26/26dB 22/22/22dB 22/22/22dB
750-1000 MHz 7.8/10.0/12.0dB 24/24/24dB 22/22/22dB 22/22/22dB
Nominal Impedance: 75 Ohm
F-Connector Type: ANSI/SCTE Compliant Sealed Brass
F-Connector Torque: 30 in. lbs. (max)
Surge Protection: 6 kV Ring Wave Surge per IEEE C62.41 Category A3 Compliant
Second Harmonic: -45 dBmV after 6 kV ring wave surge with a +55 dBmV return input carrier
Operating Temperature:-40° C to 60° C, -40° F to 140° F
