DESCRIPTION
Vehicular antenna conceived to bear high powers. The coil is made of big section copper wire
and the whip of conic 17/7PH stainless steel to get the best performance. The mount is of black
chromed brass with a rubber washer for a perfect watertightness and its UHF-PL259 connection
makes it suitable for the installation on magnetic mount. It can be supplied with "N-PL" mount
and 4m cable for a hole installation on the vehicle. Hi-Power is available in two whip versions:
1600mm and 2000mm length.
SPECIFICATIONS
Electrical Data
Type : CB Base loaded
Frequency Range : 26-28 MHz
Impedance : 50 Ω Unbalanced
Radiation : Omnidirectional
Polarization : Vertical
V.S.W.R. : ≤ 1.2 : 1
Bandwidth at V.S.W.R. 2:1
SILVER MEGAWAT 3000 : 1890 KHz
SILVER MEGAWAT 4000 : 2580 KHz
Max Power
SILVER MEGAWAT 3000 : 400 Watts
SILVER MEGAWAT 4000 : 600 Watts
Height approx.
SILVER MEGAWAT 3000 N : 1735 mm
SILVER MEGAWAT 4000 N : 2035 mm
Weight approx
SILVER MEGAWAT N : 450 gr
SILVER MEGAWAT PL : 650 gr
Mounting
SILVER MEGAWAT N : hole ∅ 12.5 mm
SILVER MEGAWAT PL : UHF-male (PL 259)
Cable lenght / type
SILVER MEGAWAT N : 4 m / RG 58
SILVER MEGAWAT PL : Not supplied
ID211
Tuning
Adjusting
N-PL-AS NE-PL-AS
Alternative Mount
MAG 145 PL - MAG 160 PL
Alternative Magnetic Mount
HI-QUALITY ANTENNAS MADE ITALY
