connection
1 Ph + N
1 Ph + N
1 Ph + N
1 Ph + N
min.
diameter of
cable
3 x 1mm²
3 x 1mm²
3 x 1mm²
3 x 1mm²
fuse
16 A
16 A
16 A
16 A
network voltage
FV200 / 220-240V ~50Hz
FV260 / 220-240V ~60Hz
FV200 / 220-240V 3N ~50Hz
FV260 / 220-240V 3N ~60Hz
8
Connection to the mains
When installing the appliance or replacing the power supply cable (H05
RR-F 3x1mm², H05 RN-F 3x1mm² or H05 VV-F 3x1mm²), completely uns-
crew the connection screws before attaching the wires to the appro-
priate terminals.
The earth wire must be connected to the terminal on the appliance.
If you require fixed connection, ensure that an omnipolar switch is placed in the
mains supply conduit, respecting a contact distance of at least 3mm. If not, the
appliance must be positioned in such a way that the mains plug remains acces-
sible when the apparatus has been installed.
We cannot accept any liability in the event of an accident resulting from
non-existent or faulty earthing.
Operating voltage / FV200.............................................................220 - 240 V
~
50 Hz
Operating voltage / FV260.............................................................220 - 240 V
~
60 Hz
Total power of oven ....................................................................................... 2,03 kW
Energy consumption
-Heating to 100°C and maintaining temperature for 1 hour ................................. 1 kWh
Inside dimensions of oven
Width ........................................................................................................... 38,5 cm
Height .......................................................................................................... 18,2 cm
Depth ........................................................................................................... 33,5 cm
Effective volume ...................................................................................... 23,5 litres
These appliances comply with Directives 73/23/CEE and 89/336/CEE.
How to install your oven
E
lectrical connections
