1
5-4
powermax1000
Service manuel
NOMENCLATURE DES PIÈCES – TORCHE ET CONSOMMABLES
Torche machine T60M
Numéro
Article de référence Description Qté
083175* T60M machine torch assembly with 15 ft (4.6 m) lead
083174* T60M machine torch assembly with 25 ft (7.6 m) lead
083176* T60M machine torch assembly with 35 ft (10.7 m) lead
083177* T60M machine torch assembly with 50 ft (15.2 m) lead
083209* T60M machine torch assembly with 75 ft (22.5 m) lead
1 128640 Kit: T60M torch main body replacement 1
2 027889 Retaining clip 1
3 058519 O-ring 1
4 128639 Kit: Cap sensor replacement 1
5 075571 Cap sensor screws 2
6 128521 Kit: T60/T60M torch head repair 1
7 128643 Kit: T60M Torch Mounting Sleeve Replacement 1
8 075004 Torch mounting screws 3
9 128710 Torch positioning sleeve 1
10 128634 Kit: 15 ft (4.6 m) torch lead replacement 1
11 128633 Kit: 25 ft (7.6 m) torch lead replacement 1
12 128635 Kit: 35 ft (10.7 m) torch lead replacement 1
13 128641 Kit: 50 ft (15.2 m) torch lead replacement 1
14 128894 Kit: 75 ft (22.5 m) torch lead replacement 1
15 128638 Kit: ETR connector replacement 1
128645 Kit: T60M Torch mounting (for reassembly after installation) 1
* L’ensemble supérieur comprend les consommables suivants (voir les Configurations des consommables de la
T60M qui donne les descriptions des pièces consommable) :
120926 Electrode 1
120925 Swirl ring 1
120928 Retaining cap 1
120930 Shield 1
120931 Nozzle 1
