Cybex 17001 Jungle Gym - Manuel (Page 6)

Guide du propriétaire Cybex
6
Autocollants d’ avertissement/mise en garde
Les autocollants d’avertissement indiquent une situation potentiellement dangereuse, qui, si elle
n’est pas évitée, pourrait entraîner des blessures graves voire la mort.
Les autocollants de mise en garde (Attention) signalent une situation potentiellement dangereuse
qui, si elle n’est pas évitée, risque d’entraîner des blessures légères ou moyennes.
Les autocollants d’avertissement/mise en garde utilisés sur l’équipement sont illustrés ci-dessous.
Les diagrammes après les autocollants indiquent l’emplacement de chaque autocollant
