4
CHW3070 / CHW3070S
3. INSTALLATION
1. In case it was transported or stored horizontally, place the dispenser in an upright
position for at least 4 hours before plugging it into the socket.
2. Remove the tamper seal label from the cap of the bottle. Do not remove the cap.
3. Gently insert the bottle vertically into the water guard and press the taps until the
water flows out from the RED (hot) tap.
4. Insert the power plug into a properly grounded socket, then turn on the switches
(DON'T TURN ON THE SWITCHES AT THE SAME TIME) to start the machine, the heating
lamp and the cooling lamp light up. It will stop or start working automatically when the
water temperature reaches the factory temperature settings.
5. If you do not want to dispense hot water, turn off the hot water switch on the back
of the unit (Red color)
6. If you do not want to dispense cold water, turn off the cold water switch on the back
of the unit (Green color)
4. WARNING
1. Replace bottle as soon as you notice it is empty. Unplug unit if bottle and tanks are
empty.
2. This unit dispenses water at temperatures that can cause severe burns. Avoid direct
contact with hot water.
3. Keep children away from unit while dispensing.
4. Never allow children to dispense hot water without proper and direct supervision.
5. Prior to use, this dispenser must be properly assembled and installed in accordance
with this manual.
6. This dispenser is intended for water use only. Do NOT use other liquids.
7. For indoor use only. Keep water dispenser in a dry place away from direct sunlight.
8. Install and use only on a hard, flat and levelled surface.
9. Do NOT place dispenser into an enclosed space or
cabinet. Always maintain its distance more than 15cm
from the wall. There should be a distance of 15cm on
the left and right side.
10. Make sure the adoption of the earth wire with
Three Pin-hole Socket and the Electric Leakage
Protector is available to avoid any electric shock.
11. Do not use an extension cord with your water
dispenser.
12. Always grasp plug and pull straight out from outlet.
Never unplug by pulling on power cord.
13. Do NOT use dispenser if the cord or plug is
damaged.
14. To protect against electric shock, do NOT immerse
