6
CHR4070 / CHR4070S
6. CLEANING COLD TANK
Recommended to be done every 2 to 3 months depending on the water type
1. Best to do prior to loading a fresh bottle
2. Turn off both switches on back
3. Unplug power cord
4. Remove water bottle
5. Place at least a 10 Litre bucket under the drain of the dispenser (found on the
back side)
6. Remove drain cap and silicon plug. Cold water will flow into the bucket. This
will be followed several seconds later by hot water at temperatures that can cause
severe burns. Avoid direct contact with hot water.
7. Place drain cap and silicon plug in a safe location so they are not lost.
8. Keep children away while draining the dispenser
9. Remove remaining water from the reservoirs by dispensing from both taps
10. Replace silicon plug and drain cap
11. Remove water guard (1) assembly by turning it counter clockwise.
12. Clean water guard assembly with a soft cloth using a cleaning mixture with 2%
cooking citric acid and 5 litres of clean water and then rinse the water guard and
place it on a clean cloth.
13. Pour remaining cleaning mixture into the tank
14. Dispense all cleaning mixture through the both taps
15. Wipe inside of reservoir and area around both taps with a soft cloth
16. Rinse system twice by dispensing 5 litres of tap water through both taps
17. Make sure all water has been dispensed.
18. Replace water guard assembly
19. Repeat INSTALLATION procedure as mentioned previously
7. TROUBLESHOOTING
Dispenser does not operate.
- Make sure the power cord is properly connected to a working outlet.
Water is leaking.
- Bottle may have a leak. Remove bottle and replace with new bottle.
No water is coming from the taps.
- Make sure the bottle is not empty. If so replace it.
- Make sure to push the water controls in fully.
Cold water is not cold.
- Make sure the switch is on and the plug is in the socket.
- Check the fuse and replace if necessary.
- It takes up to one hour after setup to dispense cold water.
- Make sure the back of the dispenser is at least 15cm from a wall
ENG
