Campomatic CHR4070 - Manuel (Page 4)

4
CHR4070 / CHR4070S
2. FEATURES
1. The dispenser supplies hot and cold temperature water to meet the demands of
people for drinking coffee or tea and having instant food or milk, cold drink, etc. It's
suitable for households, hotels, offices and schools, etc.
2. Up to five gallon (20 litres) bottle of pure water or RO-Purified water can be used
as the water source.
3. Powerful compressor refrigeration technology and exact temperature control
technology are adopted. It provides fast cooling and high efficiency.
4. The cooling tank and the heating tank are made of food grade stainless steel. They
are long-use, safe and sanitary.
3. INSTALLATION
1. In case it was transported or stored horizontally, place the dispenser in an upright
position for at least 4 hours before plugging it into the socket.
2. Remove the tamper seal label from the cap of the bottle. Do not remove the cap.
3. Gently insert the bottle vertically into the water guard and press the taps until the
water flows out from the RED (hot) tap.
4. Insert the power plug into a properly grounded socket, then turn on the switches
(DON'T TURN ON THE SWITCHES AT THE SAME TIME) to start the machine, the
heating lamp and the cooling lamp light up. It will stop or start working automatically
when the water temperature reaches the factory temperature settings.
5. If you do not want to dispense hot water, turn off the hot water switch on the back
of the unit (Red color)
6. If you do not want to dispense cold water, turn off the cold water switch on the
back of the unit (Green color)
4. WARNING
1. Replace bottle as soon as you notice it is empty. Unplug unit if bottle and tanks are
empty.
2. This unit dispenses water at temperatures that can cause severe burns. Avoid
direct contact with hot water.
3. Keep children away from unit while dispensing.
4. Never allow children to dispense hot water without proper and direct supervision.
5. Prior to use, this dispenser must be properly assembled and installed in
accordance with this manual.
6. This dispenser is intended for water use only. Do NOT use other liquids.
7. For indoor use only. Keep water dispenser in a dry place away from direct sunlight.
8. Install and use only on a hard, flat and levelled surface.
ENG
