4 — English © 2010 Baja, Inc. All Rights Reserved.
NOTE: Having two people available will make the assembly
process easier, even if using an overhead hoist.

Carefully cut packing straps and remove cardboard carton
from metal frame.
WARNING:
Do not stand at the front or the rear of the dirt bike while
the straps are being cut. Keep the carton level while lifting
and do not allow it to tip forward or backward. Failure to
follow these instructions could result in serious personal
injury.
 Remove manufacturer’s statement of origin, assembly
guide, operator’s manual, and assembly hardware.
 Remove all bolts, brackets, and ties that attach the metal
shipping crate to the dirt bike. See figure below.
 With a person on each side, carefully lift shipping crate
off the dirt bike and set aside.
NOTE: If a second person is unavailable, use an overhead
hoist to lift and remove the metal frame.
WARNING:
Carefully support the crate at all times during the removal
process. Allowing the crate to drop could cause serious
injury and/or damage the dirt bike.
 Remove and set aside all packaging and wrap from unit
and parts. Do not discard the packing material until you
have carefully inspected and satisfactorily operated the
product.
WARNING:
If any parts on the Loose Parts List are already assembled
to your product when you unpack it, verify the part is as-
sembled correctly, is properly tightened, and is torqued
correctly (where applicable) before proceeding to the next
assembly step. Use of a product that may have been im-
properly assembled could result in serious personal injury.
 Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
 If any parts are damaged or missing, please call
1-888-863-2252 for assistance.
UNPACKING
