OCTO-QUATTRO™
PAGE 5
ENGLIS
H
OCTO-QUATTRO ™
Chapter 1 : INTRODUCTION
1-1. ACCESSORIES SUPPLIED WITH YOUR DEVICE
• 1 AC Power supply cord.
• 1 VGA cable (HD15 male / male connector).
• 1 S.VIDEO (Y/C) cable (4-pin mini DIN male / 2 BNC male connectors).
• 1 Set of 5 MCO (5-pin) female connectors (for audio connection).
• 2 white labels: to rename the input selection buttons.
• 1 CD-ROM (Remote Control Software).
• 1 User’s Manual.
1-2. GENERAL INFORMATION
The OCTO-QUATTRO ™ is a computer & video up/down Scaler Switcher with 4 universal A/V inputs. It performs
an ultra fast and smooth transition between any scaled sources.
Each of the 4 inputs is fitted with a stereo audio line. The audio can either follow or break down from the video
image. The volume of each audio can be individually adjusted.
The OCTO-QUATTRO
™ can fit with the native resolution of the projection display and provide you with a high
image quality thanks to its integrated digital decoder, improved 3:2 and 2:2 Pull down circuitry, auto-adaptative
pixel by pixel 3D motion compression, Time Base Corrector. All individual image controls settings are stored in
non-volatile memories. This compact device is especially dedicated to the installation market, for entry level High
Resolution A/V Seamless presentation displays, conference and boardrooms.
Easy to use, the OCTO-QUATTRO
™ , offers auto Image centering, Auto pixel clock, Auto scan. Also an auto
projector ON/OFF through RS232 control and a jack Ø 3,5 mm powered by a +12 Vdc output, is provided.
1-3. DEVICES & OPTIONS REFERENCES
REFERENCE DESIGNATION
OTR401 OCTO-QUATTRO ™ .
OPT-LAN LAN communication port (optional)
RK802-F Remote KEYPAD for controlling an OCTO device (optional).
10077 CABLE (HD15 M / HD15 M) L = 1.8 m
10023 CABLE (HD15 M / 5BNC M) L = 1.8 m
10102 CABLE (4-pin mini DIN M / 2BNC M) L = 1.8 m
10009 CABLE (4-pin mini DIN M / 4-pin mini DIN M) L = 1.2 m (optional).
10123 CABLE (HD15 M / 5BNC F) L = 0.5 m (optional).
10124 CABLE (4-pin mini DIN F / HD15 M) L = 0.2 m (optional).
1-4. INSTALLATION
IMPORTANT: Please read all the safety instructions (pages 2 to 4) before starting.
• Table Top Mounting: The OCTO-QUATTRO ™ can be used directly on a table: the unit is equipped with 4 plastic
feet.
• Rack Mounting: The
OCTO-QUATTRO ™ is compatible with a 19" enclosure. To install the OCTO-
QUATTRO ™ into a 19” rack: Attach the OCTO-QUATTRO ™ to the rack by using 4 screws in
the front panel holes (screws are not included).
IMPORTANT:
• The openings in the rear and side panels are for cooling. Do not cover these openings.
• Be sure that no weight is added to the OCTO-QUATTRO ™ in excess of 2 kg (4.4 lbs.).
• The maximum ambient operating temperature must not exceed 40°C (104°F).
• The rack and all mounted equipment in it must be reliably grounded to national and
local electrical codes.
