OCTO-QUATTRO™
Chapter 8 : REMOTE CONTROL PROGRAMMER'S GUIDE (continued)
PAGE 25
8-4. COMMANDS AND RESPONSES TABLE (continued)
VALUE
ASCII
COMMAND
RESPONSE
COMMAND
DESCRIPTION
TYPE
MIN MAX
DESCRIPTION
IMAGE COMMANDS
H HP
Horizontal
position.
Rd/Wr
0
255
V VP
Vertical
position.
Rd/Wr
0
255
W HW
Horizontal
size.
Rd/Wr
0
255
S VS
Vertical
size.
Rd/Wr
0
255
yC ACAD
Automatic
centering.
Rd/Wr
0
1
1
= CENTERING action (automatic reset).
QA
ASP
Input aspect ratio selection.
Rd/Wr
0
2
0 = 4/3 standard
1 = 16/9 letterbox
2 = WS anamorphic.
QH QH
Horizontal
smoothing.
Rd/Wr
0
1
0 = OFF
1 = ON
B
BRG
Brightness adjustment (video).
Rd/Wr
0
255
D CON
Contrast
adjustment
(video). Rd/Wr
0
255
O
COL
Color adjustment (video).
Rd/Wr
0
255
T
HUE
Hue adjustment (video NTSC).
Rd/Wr
0
255
QO
OVR
Underscan / overscan (video).
Rd/Wr
0
1
0 = underscan
1 = overscan
QP
PROC
Sharpness adjustment (video).
Rd/Wr
0
7
0 = standard level
1 = level 1
2 = level 2.................. 7 = level 7.
K
BLK
Black level adjustment (computer).
Rd/Wr
0
255
QR
RLV
Red level adjustment (computer).
Rd/Wr
0
127
QG GLV
Green
level
adjustment (computer).
Rd/Wr
0
127
QB
BLV
Bleu level adjustment (computer).
Rd/Wr
0
127
mc
CLK
Number of pixels per line (computer). Rd
0 65535
mC DLCK
Pixels clock adjustment (computer).
This function is active if CLK ≠ 0.
Rd/Wr
0 127
QF QF
Optimize adjustment (computer). This
function is active if CLK = 0 only.
Rd/Wr
0 255
mP
DPHA
Pixels phase adjustment (computer).
Rd/Wr
0
31
yp PRES
PRESET.
Rd/Wr
0
1
1 = PRESET action (automatic reset).
AUDIO
COMMANDS
AV
AVOL
Master volume adjustment. Rd/Wr
0
255
+
AVOL
Increase the master volume.
Rd/Wr
0
255 10+ : increase the master volume of 10 steps.
-
AVOL
Decrease the master volume.
Rd/Wr
0
255 10- : decrease the master volume of 10 steps.
AO
AMOD
Auto follow or breakaway mode.
Rd/Wr
0
1
0 = auto follow
1 = breakaway
AC
ACH
Audio input selection.
Rd/Wr
1
4
1 = AUDIO IN #1.
2 = AUDIO IN #2
3 = AUDIO IN #3
4 = AUDIO IN #4
AL
ALVL
Audio level (works with PC command). Rd/Wr
0
63
AB
ABAL
Audio balance (works with PC).
Rd/Wr
0
63
AM AMUT
Audio
mute.
Rd/Wr
0
1
0 = MUTE OFF
1 = MUTE ON
NOTE:
Rd/Wr = Read and write command.
Rd = Read only command.
