Whirlpool 30 Inch Combination Smart Wall Oven Control Guide - Manuel (Page 3)

3
COOKING METHOD FEATURE INSTRUCTIONS
DELAY START Delayed Start Delay Start is used to enter the starting time for an oven function with a delayed start.
Once the cooking method is selected, input the bake temperature. Select DELAY and
follow the prompts on the screen.
NOTE: Delay Start should not be used for foods such as breads and cakes because they
may not bake properly.
COOK TIME Timed
Cooking Cook Time allows the oven to be set to turn on at a certain time of day, cook for a set
length of time, and/or shut off automatically.
AIR FRY
(for connected models,
when connected)
*
Air Frying
1. Press the Oven Power or Upper or Lower keypad for the desired oven.
2. Select COOKING METHODS.
3. Select AIR FRY.
4. Select the desired temperature by scrolling left to right or manually by selecting the
grid in the upper right corner and entering the Air Fry temperature into the keypad.
5. Select START to begin preheating. A tone will sound when preheating is complete.
6. Press the Oven Cancel on Upper keypad when finished.
NOTE: The convection fan and oven elements will shut off when the oven door is opened.
All timers, including any active Cook Time or Timed Cook functions, will continue to count
down.
Favorites
The Favorites feature stores the oven mode and temperature for
your favorite recipe. As you continue to utilize your Favorites tool,
your product will refine and tailor suggestions towards your
cooking cravings/needs.
NOTE: A select set of favorites and suggestions may be
automatically shown on the Home screen based on your meal
times.
To save a recipe, select the Favorites keypad and follow the
prompts on the screen to customize your favorites.
Add an image or name to the favorite to customize it to your
preferences.
Assisted Cooking
Assisted cooking helps you select the right mode for your
everyday cooking needs.
Some modes allow you to skip preheat. Follow the prompts on
screen for guidance throughout the cooking process.
Assisted
Cooking
Modes Food
Selections Tips for Best Results
FROZEN Frozen Pizza
Frozen Pie
Frozen Fries
Frozen
Lasagna
Frozen Nuggets
Frozen Meals Frozen foods do not require
preheat. Insert food right away.
Input the manufacturer’s
maximum recommended time
and temperature.
For more information, see the
“Frozen Bake
™ ” section.
Tools
The Tools keypad allows you access to functions and
customization options for your oven. These tools allow you to set
the clock, change the oven temperature between Fahrenheit and
Celsius, turn the audible signals and prompts on and off, adjust
the oven calibration, change the language, and more.
Select the Tools keypad to view the Tools features:
� Remote Enable
� Kitchen Timer
� Light
� Self-Clean
� Mute
� Control Lock
See the “More Modes” section for more information.
Tools Available Selections
Remote Enable Select REMOTE ENABLE to enable
the ability to utilize the Whirlpool
®
app.
NOTE: Remote Enable does not turn
off when the door is opened. Do not
store any flammable materials or
temperature sensitive items inside
the oven.
Kitchen Timer Set a Kitchen Timer by manually
entering the desired time into the
keypad.
1. Select KITCHEN TIMER.
2. Manually input the time to the
desired timer length.
3. Select START.
4. Select the Cancel keypad to end
the Kitchen Timer.
Light Select LIGHT to turn the light on and
off. When the oven door is opened,
the oven light will automatically turn
on.
Turntable Turn the Turntable on or off.
Self-Clean Self-Clean option is not available for
the microwave oven.
For further information, see the
“Self-Cleaning Cycle” section in the
Owner’s Manual.
Mute Select MUTE to Mute and Unmute
the sound.
*Wi-Fi & App Required. Features subject to change. Details and privacy info at whirlpool.com/connect.
