en-us Electrical connection
22
Electrical connection 12 Electrical connection
Electrical connection Read these instructions to safely connect your appliance to the electrical supply.
12.1 Electrical requirements
Make sure your electrical installation supports the follow-
ing requirements.
This appliance must be supplied with the proper voltage
and frequency and connected to an individual, properly
grounded branch circuit, protected by a circuit breaker or
fuse. To know the circuit breaker or fuse required by your
model, see the rating plate to find the wattage consump-
tion and refer to the ratings table to get the circuit breaker
or fuse amperage.
All oven models on the front cover of this Installation In-
structions are dual rated, designed to be connected to ei-
ther 208 V or 240 V AC, 60 Hz, 4-wire, single-phase
power supply.
Model Circuit required Watts @ 240 V Circuit required Watts @ 208 V
HBL5351UC,
HBL5344UC
30 A 6300 30 A 4800
HBL5451UC, HB-
N8451UC,
HBL8454UC,
HBL8453UC,
HBL8443UC,
HBL8444LUC,
HBL8444RUC,
HBLP454UC,
HBLP451UC,
HBLP451LUC,
HBLP451RUC
30 A 6400 30 A 4800
HBL5551UC 40 A 6000 30 A 4500
HBL5651UC,
HBL8651UC,
HBL8642UC
40 A 8500 40 A 6500
HBL57M52UC,
HBL87M53UC
40 A 8000 40 A 6500
HBL5754UC,
HBL8753UC,
HBL8743UC,
HBLP752UC
40 A 9600 40 A 8400
HBN8654UC 40 A 8600 40 A 6600
HBLP651UC,
HBLP651LUC,
HBLP651RUC
40 A 9200 40 A 7000
HSLP751UC 40 A 8400 40 A 6400
12.2 Location of the power outlet
Before you install the appliance, check the location of the
power outlet.
¡ If the electrical supply is located in the cabinet opening,
the electrical connection must be made prior to placing
the oven in the opening.
¡ If the electrical supply is in an adjacent cabinet, electri-
cal connection can be made after placing the oven in
the opening.
12.3 Routing the electrical conduit cable
Requirements
¡ A hole in the cabinet has been prepared to route the
electric conduit from the oven to the junction box.
¡ Serviceability must be maintained. Do not shorten the
electric conduit cable. Route the electric conduit cable
in a way to permit temporary removal of the oven.
▶
The electrical conduit cable swivels where it is con-
nected at the oven. Rotate the electric conduit cable up-
ward or downward and direct it through the prepared
hole in the cabinet.
