EN
9
4 - Cooktop Installation Over a Single Oven
CAUTION
• Use the countertop opening dimensions that are given with
these Instructions.
• Check the cooktop base for an approved installation label.
Verify approved oven model numbers that can be installed
with your cooktop model number.
• The cooktop may be installed over a single oven.
• The cooktop should be centred over the oven.
• Both the cooktop and the oven must be installed according
to each specific installation instruction.
* The ventilation opening is to extend the full length of the cooktop cutout.
25” (635mm)
min
19 7/16” (494mm)
3”
(76mm)
2 1/2”
(65mm)
1 5/8”
(40mm)
max
1/4”
(6mm)
min
4”
(101mm)
min
4 3/4”
(120 mm)
36”
(915mm)
27 1/4”
(692mm)
1 1/2”
(38 mm)
min
24” (610mm)
min
*1/4”
(6mm)
min
2 1/2”
(64mm)
