LG Multi F Series 18,000 BTU Multi F Single Compatible Inverter Heat Pump Low Static Ducted Ceiling Indoor Unit Owners Guide - Manuel (Page 9)

Operating Introductions
Owner's Manual 9
ENGLISH
It supplies warm wind to the indoor
TEMP
FAN
SPEED
OPER
MODE
If you want to set the heating operation,
press the button. And press the
button. 1
If you press the button, the cooling
operation will stop. 4
If you prees the mode button during the
operation, the operation mode will be
changed in the order of cooling,
dry(dehumidification),heating,auto-operation
and fan operation. 3
Set the desired room temperature higher
than the current room temperature.
- Setting temp range : 16°C~30°C (60°F~86°F)
- If the desired temperature is set lower than
the current room temperature, the heating
function will not begin.
2
TEMP
A click of the button will increase the
desired temperature by 1°C or 2°F.
A click of the button will decrease the
desired temperature by 1°C or 2°F.
OPER
MODE
What is the three-minute delay function?
It will take time for the product to blow warm air. The delay is to protect the compressor.
The room will be heated with warm air after three minutes when the compressor begins
operation.
Standard Operation - Auto Operation
In this operation mode, the system is automatically operated by the electronic controls.
- You can set the desired temperature between 18°C(64°F) and 30°C(86°F) for Auto Operation mode.
This function properly operates when you use the remote controller matching each model.
NOTE
Standard Operation - Heating Mode
