27
SOLO6 - TWIN6 - SUB12
Professional Analogue Monitoring System - User Manual
EN
All specifications are subject to change.
Performance SUB12
• Frequency response (@ -3dB) 30Hz - 400Hz
• Low cut-off frequency (@ -6dB) 28Hz
• Maximum SPL
(Average CEA2010B 30-200 Hz free field @ 1m) 124.5dB
Electronic section
• Input Balanced XLR LFE 10kΩ, Left & Right 10kΩ
• Outputs Balanced XLR LFE (in parallel), Left & Right 50Ω
• Bass amplifier stage 600W RMS
• Nominal power supply ~100–120 VAC/220–240 VAC
50/60Hz
• Rated power consumption 180W
• User controls Sensitivity, Stand-by, Polarity, Phase, LPF, Volume, HPF
• Fuses ~100-120V, T10AL/250V
~220-240V, T5AL/250V
• Internal signal processing and functions
- Subwoofer section Left/right mono summation
LFE + mono low-pass
24dB/octave
Phase adjustment
Polarity selection
Switchable high-pass crossover,
frequency cut-off selection
24dB/octave
• Outputs (to satellites)
- Type/Impedance
- Connector Right, left
Electronically balanced / 50Ω
3-point male XLR
Transducers
• Bass 1 x 13" (33cm) x ‘W’ cone
• Shielding no
Loudspeaker
• Construction 1 1/8 " (30mm) MDF
• Finish Dark red natural veneering side panels, black body
• Dimensions (HxWxD) 23 5/8 x19 1/8 x22 3/8 " (600x487x568mm)
• Weight 127.8lbs (58kg)
• Temperature range During use: 5-35°C
In storage: 0-50°C
