EXM
1
Introduction
Congratulations on your purchase of the EXM 70/Mobile/Mobile12. This compact PA enclo-
sure has been designed with enough features to handle live performances and small DJ gigs
while being the ultimate in portability.
Some features of the Yorkville EXM 70/Mobile/Mobile12 include:
• Compact PA enclosure with a built in 3 channel mixer with effects
• Battery life of 5.5 hours when playing at full volume; well in excess of 24 hours of life for
light-duty applications (EXM Mobile/Mobile12)
• 3 Mic inputs (XLR, all channels), Balanced line input (1/4-inch CH1), Instrument input
(Unbal 1/4-inch CH2), Aux Input (1/8-inch CH3)
• Bluetooth™ connection for streaming audio to the system (via Channel 3)
• Scalable, the design allows the system to grow to meet different needs
• Easily paired with a compact Subwoofer to extend the bass
• Link input/output for connecting two or more EXM 70/Mobile/Mobile12 systems together
• Effects including Reverb and delay
This manual explains the various features and functions of the EXM 70/Mobile/Mobile12. For
general information about mixing and other facets of sound-reinforcement check out our P.A.
User Guides available on our website (http://www.yorkville.com)
System Configurations
The scalable nature of the Yorkville EXM 70/Mobile/Mobile12 allows for several configurations that
can be utilized to suit your needs. Here are some examples:
MONO
(Single System)
MONO - LINKed
(2x EXM Mobiles)
LINK
MONO - LINKed with
1x SUB (2x EXM Mobiles)
LINK
LINK
MONO w/SUB
(Single System)
LINK
STEREO
(2x EXM Mobiles)
STEREO w/1x SUB
(2x EXM Mobiles)
LINK
STEREO w/2x SUBs
(2x EXM Mobiles)
LINK LINK
